Starter for Forklift - The starter motor these days is typically either a series-parallel wound direct current electric motor that includes a starter solenoid, which is similar to a relay mounted on it, or it can be a permanent-magnet composition. When current from the starting battery is applied to the solenoid, mainly via a key-operated switch, the solenoid engages a lever which pushes out the drive pinion that is situated on the driveshaft and meshes the pinion using the starter ring gear which is seen on the engine flywheel.
The solenoid closes the high-current contacts for the starter motor, which begins to turn. After the engine starts, the key operated switch is opened and a spring in the solenoid assembly pulls the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This allows the pinion to transmit drive in just one direction. Drive is transmitted in this particular manner through the pinion to the flywheel ring gear. The pinion continuous to be engaged, like for instance since the operator did not release the key as soon as the engine starts or if there is a short and the solenoid remains engaged. This causes the pinion to spin separately of its driveshaft.
This aforesaid action prevents the engine from driving the starter. This is an essential step for the reason that this type of back drive would allow the starter to spin really fast that it will fly apart. Unless adjustments were done, the sprag clutch arrangement will prevent using the starter as a generator if it was utilized in the hybrid scheme mentioned earlier. Usually an average starter motor is meant for intermittent use which will prevent it being used as a generator.
The electrical parts are made to function for more or less 30 seconds to prevent overheating. Overheating is caused by a slow dissipation of heat is due to ohmic losses. The electrical components are intended to save cost and weight. This is the reason most owner's handbooks utilized for automobiles suggest the driver to stop for at least 10 seconds right after each ten or fifteen seconds of cranking the engine, whenever trying to start an engine that does not turn over at once.
During the early part of the 1960s, this overrunning-clutch pinion arrangement was phased onto the market. Prior to that time, a Bendix drive was utilized. The Bendix system operates by placing the starter drive pinion on a helically cut driveshaft. When the starter motor begins spinning, the inertia of the drive pinion assembly enables it to ride forward on the helix, hence engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear allows the pinion to go beyond the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.
The development of Bendix drive was made in the 1930's with the overrunning-clutch design called the Bendix Folo-Thru drive, developed and introduced in the 1960s. The Folo-Thru drive consists of a latching mechanism together with a set of flyweights inside the body of the drive unit. This was a lot better as the average Bendix drive utilized to be able to disengage from the ring as soon as the engine fired, though it did not stay functioning.
When the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. As soon as the drive unit is spun at a speed higher than what is achieved by the starter motor itself, for instance it is backdriven by the running engine, and after that the flyweights pull outward in a radial manner. This releases the latch and allows the overdriven drive unit to become spun out of engagement, therefore unwanted starter disengagement could be avoided prior to a successful engine start.
